Tropaeolaceae

Disclaimer

Content is from Kirkbride et al. 2006Kirkbride et al. 2006:
Kirkbride JH, Jr, Gunn CR, and Dallwitz MJ. 2006. Family guide for fruits and seeds, vers. 1.0. Accessed September 2020-January 2022. URL:  https://nt.ars-grin.gov/seedsfruits/keys/frsdfam/index.cfm ., without modification.
Updates are forthcoming.

Taxonomy

Tropaeolaceae Jussieu ex A.P. de Candolle

Common name: Nasturtium Family.

Number of genera: 1 genus.

Number of species (Mabberley 1997): 88 species.

Disseminule

Fruit (intact or entire).

Description

Fruits: Pistil(s) compound; 1; 1-pistillate; with carpels united. Fruit pericarpium; simple, or schizocarpschizocarp:
usually dry fruit splitting between two or more locules to form distinct, indehiscent, usually one seeded segments; fruit derived from a single, superior or inferior, compound ovary; compare to mericarp
; samarasamara:
a winged, indehiscent, dry fruit containing a single (rarely two) seed(s)
(was Magallana); baccarium; with persistent central column; valves not diverging at top of central column; not within accessory organ(s); 1-seeded to more than 1 but less than 10-seeded; 1–3-seeded; from 1–5 cm long; 1.5 cm long; with 1–3-carpellate; with carpels united; with carpels remaining united at maturity; with carpels not radiating at maturity; with carpels remaining connected at stylestyle:
in a flower, the narrow and elongated part of the pistil between the stigma and the ovary; sometimes persisting in fruit
; without sterilesterile:
lacking male and/or female reproductive parts; also, not producing fruit or seed
carpels; not sulcatesulcate:
surface relief—having one or more elongate, relatively narrow and shallow depressions or grooves
; in transection angledangular:
2D shape—having sides that meet at acute or obtuse angles
, or tereteterete:
approximately circular in cross section; width and thickness approximately equal
; 3-angled (was Magallana); apexapex:
the point farthest from the point of attachment, or the "tip" of an organ
not beaked; indehiscentindehiscent:
not opening on its own, as in a fruit
. Epicarpepicarp:
outer layer of fruit wall or pericarp, if divided into layers; note here used synonymously with exocarp
brown (all shades), or purple (spotted); dulldull:
reflecting only a low proportion of incident light, with no apparent sheen
; durable; glabrousglabrous:
without hairs
; without armature; smooth, or not smooth; rugoserugose:
wrinkled
; without wing(s), or with wing(s) (was Magallana); 3-winged; with wing(s) laterallateral:
(of embryo) embryo lies along the side of the seed, generally towards one end; of, at, or from the side; in grasses, can refer to the sides adjacent to the dorsal and ventral sides
; without apicalapical:
at or pertaining to the end of the seed or fruit distal from its point of attachment (i.e., base)
respiratory hole. Mesocarpmesocarp:
the middle layer of the pericarp, if divided into layers
present, or absent. Endocarpendocarp:
the inner layer of the pericarp, if divided into layers
present, or absent; not separating from exocarpexocarp:
outer layer of fruit wall or pericarp, if divided into layers; note here used synonymously with epicarp
; thin; not splitting into 1-seeded pyrenes; smooth; without wing; without operculumoperculum:
a dehiscent cap (or lid) of a seed or fruit that opens during germination or dehiscence
; without secretory cavities; without mechanism for seedling escape; without grooves; without longitudinallongitudinal:
of or relating to length or the lengthwise dimension
ridges. Funiculusfuniculus:
(alt. funicle) stalk connecting the ovule (later seed) to the ovary (later fruit) placenta
short; short without seed bearing hookswith hooks:
bristles or spines with curved or backwards pointing tips, or with secondary bristles along their length
(retinacula); not persisting in fruit after seed shed.

Seeds: Arilaril:
(broad sense) appendicular structure that wholly or partly envelops a seed and is produced from or a modification of the funicle, raphe, or outer integument; usually fleshy or pulpy, sometimes spongy or tufted-capillate, often brightly colored
absent. Seed larger than minute; in transection tereteterete:
approximately circular in cross section; width and thickness approximately equal
; not bowl shaped; not nutlike; without winglike beakbeak:
a usually firm, terminal appendage, sometimes tapered
; without caudatecaudate:
tapering to a long, tail-like appendage
appendage(s); at maturity without food reserves, or with food reserves; with endosperm; without canavanine. Sarcotestasarcotesta:
pulpy or fleshy outer layer of the seed coat, simulates aril
absent. Testatesta:
seed coat
present; without markedly different marginalmarginal:
at, on, or close to the margin or border
tissue; without fleshy or leatheryleathery:
texture—moderately thick, tough, and very pliable
layer over hard layer; tight; without crease or line separating cotyledons from hypocotyl-radicle; without notch along margin where cotyledons from hypocotyl-radicle tip approach each other; without glands; without bristles; glabrousglabrous:
without hairs
; without wings; without collar; without operculumoperculum:
a dehiscent cap (or lid) of a seed or fruit that opens during germination or dehiscence
; colored; monochrome; brown (all shades); firm ( "cartilaginouscartilaginous:
texture—firm, dense, tough, somewhat pliable, and resilient, like cartilage
"); not becoming mucilaginousmucilaginous:
resembling mucilage; moist and sticky
when wetted; surrounding food reserve. Endosperm development nuclear. Embryo differentiated from food reserve; well developed; 1 per seed; completely filling testatesta:
seed coat
(no food reserve); 1 times the length of food reserve; at one end of seed not extending into a depression or cup; foliatefoliate:
appearing leaf-like
; with investinginvesting:
(of embryo) embryo is nearly or completely filling seed coat, straight, and axile and centric with spatulate cotyledons and covering the stalk for at least half its length; (of cotyledons) cotyledons spatulate and covering the stalk for at least half its length
cotyledons; straight; parallel to seed length; with cotyledons abruptly connected to hypocotyl-radicle; without coleorhiza; without simmondsin; with cotyledons containing euric acid; without stomata; not green; with 2 or more cotyledons. Cotyledons 2; well developed; 0.8 times length of embryo; somewhat to significantly wider than hypocotyl-radicle; many; partially concealing hypocotyl-radicle; not foliaceous; massive; flat; smooth; with apicesapex:
the point farthest from the point of attachment, or the "tip" of an organ
entire; with margins when young separate and connate (when older cohering); basally cordatecordate:
2D shape—heart-shaped, with attachment at or near the broad end (compare obcordate)
; equal in size; not punctatepunctate:
surface relief - dotted with pits or with translucent, sunken glands or with colored dots, similar to pitted
dotted. Hypocotyl-radicle small; straight; not thickened.

Distribution

General distribution: New World.

Detailed distribution: Middle America and South America.

References

Literature specific to this family: Sparre, B. & L. Andersson. 1991. A taxonomic revision of the Tropaeolaceae. Opera Bot. 108:5–139.

General references: Corner, E.J.H. 1976. The seeds of Dicots, esp. vol. 2. Cambridge University Press, New York, Cronquist, A. 1981. An integrated system of classification of flowering plants, 1,262 p. Columbia University Press, New York, Engler, A. & K. Prantl. 1924 and onward. Die Natürlichen Pflanzenfamilimien. W. Engelman, Leipzig, Gaertner, J. 1788–1805. De fructibus et seminibus plantarum. The Author, Stuttgart, Goldberg, A. 1986 (dicots) & 1989 (monocots). Classification, evolution, and phylogeny of the familes of Dicotyledons. Smithsonian Contr. Bot. 58 for dicots (314 pp.) & 71 for monocots (74 pp.). [Goldberg's illustrations are reproduced from older publications and these should be consulted], Gunn, C.R., J.H. Wiersema, C.A. Ritchie, & J.H. Kirkbride, Jr. 1992 & amendments. Families and genera of Spermatophytes recognized by the Agricultural Research Service. Techn. Bull. U.S.D.A. 1796:1–500, Hooker, J.D. 1873 and forward. Icones Plantarum. William & Norgate, London. (plate number cited in text within [ ]), LeMaout, E. & J. Decaisne. 1876. A general system of botany, 1,065 p. Longmans, Green, & Co., London, Mabberley, D.J. 1987. The plant-book, 706 p. Cambridge University Press, Cambridge, and Spjut, R.W. 1994. A systematic treatment of fruit types. Mem. New York Bot. Gard. 70:1–182.
